Schrader Programmable OE Quality Tire Pressure Monitoring Sensor 20078
Tap image to zoom
Tap image to zoom

Schrader Programmable OE Quality Tire Pressure Monitoring Sensor 20078

Shop All Schrader
Part # 20078
SKU # 269741
Price Not Available
Part #
Valve Cap Included
Valve Color
Housing Material
Valve Core Material
Nickel Plated
Mounting Hardware Included

Schrader is the global leader in both OE and after market TPMS sensors. Schrader has been supplying OE TPMS sensors since 1997, well before TPMS was mandated by the tread act. Schrader supplies OE quality TPMS sensors, service kits and tools to the tire service provider who wants to be at the forefront in TPMS service. Schrader revolutionized TPMS with the markets first programmable sensor in 2008, and has further changed the market with a single programmable sensor, covering 314.9, 315 and 433 MHz applications. Schrader enables shops of all sizes to participate in the profit building benefits of TPMS. The Schrader programmable sensor is everything you need in a TPMS sensor combined into one easy to program, OE quality sensor that comes with both clamp-in and snap-in stem options.

  • checkmark
    Replaces OE sensors 4F0907275, 4F090727B, 4F0907275D, 7P0907275, 7PP907275B. 7PP907275F, 22887, 239298, 282189, 95560602100, 95836166100, 99760602120, CD23-360674-CA, 24887, AD43-360671-AA, 11B0015CP
  • checkmark
    OE quality designed sensor and valve
  • checkmark
    Aluminum nut torque - 35 in-lbs (4 Nm)
  • checkmark
    Valve core torque - 3.5 in-lbs (0.4 Nm)
  • checkmark
    Use service kit 20023 to replace the nut, grommet, cap and core, or use service kit 20037, 20038, 20039 or 20040 (based on valve length) to replace the entire valve assembly
