Delphi Fuel Pump CFG1906

Shop All Delphi
Delphi741831
Part # CFG1906
SKU # 741831
Price Not Available
In stock|
Estimated delivery Feb. 28
Warranty
Part #CFG1906
SKU #741831
Weight3.58lbs
Strainer IncludedYes
Average Flow Rating26gph
Pump TypeElectric
Outlet Quantity1
Terminal Quantity4
Outlet Outside Diameter0.313in
Terminal GenderMale
Lock Ring IncludedNo
Regulator IncludedYes
Outlet TypeFemale Quick Connect
Gasket Or Seal IncludedNo
Average Current Draw10A
Voltage12.0VDC
Inlet TypeStrainer
Terminal TypeBlade
Fuel TypeGas
Internal Or External StrainerInternal
Resistance Ohms Empty53.0Ohms
Maximum Pressure138.0PSI
Resistance Ohms Full290.0Ohms
In Tank or ExternalIn Tank
Product Bulletins
Delphi Technologies is a Tier 1 supplier to the majority of global vehicle manufacturers and has been a manufacturer of dependable fuel pumps and fuel delivery parts for over 80 years. With over 30 OE-proprietary innovations and 150 patents in fuel technologies, Delphi Technologies is regarded as a market leader in North American fuel management with sales coverage at over 95%. Learn more about our expert-led training programs and tech hotline at 1-877-463-3574. Visit our Resource Center for helpful tips and tricks on fuel pumps, technologies, and more: https://www.delphiautoparts.com/usa/en-US/resource-center.
  • checkmark
    Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
  • checkmark
    Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
  • checkmark
    Lower amperage draws less load on vehicle's electrical system
  • checkmark
    Part is validated, tested and matched to the right vehicle application
  • checkmark
    Always be sure to check and clean fuel tank to avoid unnecessary returns
  • checkmark
    Lower failure rates due to its innovative design and durability
