Delphi Fuel Pump DHP10020

Shop All Delphi
Delphi771712
Part # DHP10020
SKU # 771712
In stock|
Estimated delivery Apr. 19
Warranty
Part #DHP10020
SKU #771712
Weight2.35lbs
Strainer IncludedYes
Average Flow Rating26.0gph
Pump TypeElectric
Outlet Quantity3
Grade TypePremium
Terminal Quantity2
Outlet Outside Diameter0.375in
Minimum Pressure12PSI
Terminal GenderFemale
Outlet TypeQuick Connect
Gasket Or Seal IncludedYes
Average Current Draw4.0A
Voltage13.5VDC
Inlet TypeStrainer
Fuel Sending Unit IncludedYes
Terminal TypePin
Fuel TypeGas
Internal Or External StrainerExternal
Resistance Ohms Empty1.0Ohms
Maximum Pressure29.0PSI
Resistance Ohms Full90.0Ohms
In Tank or ExternalIn Tank
Delphi is a Tier 1 supplier to the majority of global vehicle manufacturers and has been a manufacturer of dependable fuel pumps and fuel delivery parts for over 80 years. With over 30 OE-proprietary innovations and 150 patents in fuel technologies, Delphi is regarded as a market leader in North American fuel management with sales coverage at over 95%. Learn more about our expert-led training programs and tech hotline at 1-877-463-3574. Visit our Resource Center for helpful tips and tricks on fuel pumps, technologies, and more: https://www.delphiautoparts.com/usa/en-US/resource-center.
  • checkmark
    Delphi is a global OE manufacturer and all fuel pumps are built to Delphi's OE standards
  • checkmark
    Delphi pumps are designed to operate under extreme temperatures with quick engine starts
  • checkmark
    Metal tubes in Delphi hangers are routed so as to not contact the tank at any point eliminating noise and vibration during vehicle operation
  • checkmark
    Empty float height and float retention matches OE specifications and guarantees correct gas gauge reading
  • checkmark
    Restores fast pressure performance and system integrity, translating to better pumping through less energy
  • checkmark
    Lower failure rates due to its innovative design and durability
  • checkmark
    Part is validated, tested and matched to the right vehicle application
  • checkmark
    Lower amperage draws less load on vehicle's electrical system
  • checkmark
    Always be sure to check and clean fuel tank to avoid unnecessary returns
